Model: MT-062A Yellow powder coating
Epoxy-polyester thermosetting electrostatic spray powder coating is a hybrid material combining epoxy resin and polyester resin, offering superior flowability, decorative properties, mechanical strength, and corrosion resistance. This coating is widely used for indoor metal surface protection in automotive, home appliance, metal furniture, instrumentation, fitness equipment, and radiator industries. Its dual-resin formulation ensures excellent adhesion, impact resistance, and chemical stability, making it a preferred choice for high-performance industrial applications.
| Parameter | Specification |
|---|---|
| Density | 1.1–1.8 g/cm³ (varies by type/color) |
| Horizontal Flowability | 18–35 mm |
| Particle Size Distribution | 100% < 125 μm; >85% within 60–90 μm |
| Curing Conditions | Standard: 180°C (workpiece temp.) for 15 min |
| Low-Temperature: 160°C for 15 min | |
| Coverage Rate | 9–12 m²/kg at 80 μm film thickness (100% utilization) |
| Gloss Levels | High-gloss (>80%), Semi-gloss (40–60%), Matte (15–50%) |
| Mechanical Properties | Pencil Hardness: ≥2H (GB/T 6739-86) |
| Adhesion: Grade 0 (GB/T 9286-88) | |
| Bending Test: Pass at 3 mm taper (GB/T 11185-88) | |
| Impact Resistance: ≥50 kg·cm (GB/T 1732-93) | |
| Corrosion Resistance | Salt Spray Test: 500 h (Grade 1. GB/T 1771-91) |
| Humidity Resistance: 500 h (Grade 1. BS.3900 Part F2) | |
| Cupping Test | 6 mm deformation resistance |
This coating is primarily used for indoor metal surface protection, including:
Its adaptability to various curing conditions (standard/low-temperature) enables compatibility with diverse production schedules.
Storage: Maintain below 25°C in ventilated, dry, and clean environments. Avoid direct sunlight, fire sources, and heating equipment. Stable shelf life up to 12 months when stored under recommended conditions.
Transportation: Use air-conditioned vehicles or transport during cooler periods to prevent heat-induced degradation. Avoid exposure to moisture or humidity, which may compromise powder flowability and electrostatic properties.
