Product DescriptionMT R4-ES HJ601R is a high quality thermosetting epoxy powder coating for the
Email:services@moutainchem.com
MT R4-ES HJ601R is a high quality thermosetting epoxy powder coating for the corrosion protection of valves and fittings, manufactured from cast iron or steel. The powder coating is applied in one layer on cold surfaces by electrostatic spray application. The adhesion of MT R4-ES HJ601R to the metal substrate provides long term protection of the coated component. It ensures a reliable conservation to the function and value of the parts for the common water and gas distribution network. The applicator benefits from a modern and environmentally friendly process. Drinking water approvals are available.
| Typical value | Method | |
| Binder System | Epoxy | |
| Density | 1.30 – 1.40 g/cm³ | ISO 8130-2 |
| Gel time at 200° C | 25 – 40 sec. | modified ISO 8130-6 |
| Particle size distribution | < 32 µm = 25 – 40 % < 125 µm > 98 % | Malvern ISO 8130-1 |
| Storage stability | 6 months from date of manufacture at ≤ 23° C | |
Data Curing conditions :10 min., 190° C object temperature.
| Color | blue, ca. RAL 5015 | |
| Recommended film thickness | 120 – 220 µm | |
| Flow | smooth | |
| Gloss at 60° angle | 70 – 100 units | ISO 2813 |
| Cross cut | Gt 0 | DIN EN ISO 2409 |
